16

S/NO.200A1001

Power Switch

CONNECTION DIAGRAM

VHF antenna

GPS Antenna

Power Cable

Data cable

KS200A Connection Diagram

S/NO.200A1001

Power Switch

VHF antenna

Power Cable

Data cable

KS200B Connection Diagram
