Yamaha CVP-705B - Manual (Page 63)

Creating/Editing MIDI Songs (Song Creator)
CVP-709/CVP-705 Reference Manual
63
The explanations here apply when one of “Ch1” – “Ch16” is selected in step 5 on page 62 . With [Step Rec] turned on at
the bottom left of the display, you can input the notes one by one, using the controls below.
 Control Names and Functions
Recording Melodies via Step Recording
Event List Indicates events such as note and Voice selection which have been input. For details,
refer to
page 69 .
Song Position
(Measure: Beat:
Clock) Indicates the current Song position. Events such as note and Voice selection you have
input are recorded at the position indicated here. You can change the current position
by touching [
] or [ ] below the Measure, Beat, and Clock* respectively.
*Clock
Smallest unit for the Song position and note length. A quarter note consists of 1920 clocks.
Cursor Lets you move the cursor position.
Step Rec Turning this on shows the Step Recording display, and turning it off shows the Song
Edit display.
Velocity Determines the velocity (loudness) of the note to be entered. The velocity value can be
specified within a range from 1 to 127. The higher the velocity value, the louder the
sound becomes.
Kbd.Vel: Actual resulting velocity
Length Determines the gate time (note length) of the note to be entered.
Manual: For freely setting the gate time. Touch “Manual” and close the pop-up window by touching
“OK,” then set the gate time to any desired percentage by using the Data dial.
127
111
95
79
63
47
31
15
80% 40%
99% 20%
Normal: Staccato:
Tenuto: Staccatissimo:
