158

Before Use

Basic Guide

Advanced Guide

1

Camera Basics

2

Auto Mode /

Hybrid Auto Mode

3

Other Shooting Modes

5

Tv, Av, M, C1, and C2 Mode

6

Playback Mode

7

Wi-Fi Functions

8

Setting Menu

9

Accessories

10

Appendix

Index

4

P Mode

When the camera and TV are connected, you can also shoot
while previewing shots on the larger screen of the TV. To shoot,
follow the same steps as when using the camera screen.
However, AF-Point Zoom (= 54), MF-Point Zoom (= 79)
and MF Peaking (= 80) are not available.

Powering the Camera with Household Power

Still Images

Movies

Powering the camera with AC Adapter Kit ACK-DC80 (sold separately)

eliminates the need to monitor the remaining battery level.

1

Make sure the camera is off.

2

Open the cover.

Follow step 1 in “Inserting the Battery

Pack and Memory Card” (= 19) to

open the memory card/battery cover, and

then open the coupler cable port cover

as shown.

3

Connect the adapter to the coupler.

Insert the adapter plug fully into the

coupler.

Playback on a Standard-Definition TV

Still Images

Movies

Connecting the camera to a TV with the Stereo AV Cable AVC-DC400ST

(sold separately) enables you to view your shots on the larger screen of

the TV as you control the camera.

1

Make sure the camera and TV

are off.

2

Connect the camera to the TV.

On the TV, insert the cable plugs fully into

the video inputs as shown.

Make sure the cable plugs are in video

inputs of the same color.

On the camera, open the terminal cover

and insert the cable plug fully into the

camera terminal.

3

Display images.

Follow steps 3 – 4 in “Playback on a

High-Definition TV” (= 157) to display

images.

Correct display is not possible unless the camera video output
format (NTSC or PAL) matches the TV format. To change the
video output format, press the [

] button and choose

[Video System] on the [ ] tab.
