159

Before Use

Basic Guide

Advanced Guide

1

Camera Basics

2

Auto Mode /

Hybrid Auto Mode

3

Other Shooting Modes

5

Tv, Av, M, C1, and C2 Mode

6

Playback Mode

7

Wi-Fi Functions

8

Setting Menu

9

Accessories

10

Appendix

Index

4

P Mode

Using an External Microphone

An external microphone with a mini plug (3.5 mm diameter) can be

connected to the external microphone IN terminal (= 3) for use in

recording. Note that the built-in microphone is not used for recording when

an external microphone is connected.

Open the cover and connect the

external microphone.

Any attenuator settings you have configured are also applied to
recording with the external microphone (= 69).

Connecting an external microphone will deactivate [Wind Filter]
(= 69).

4

Insert the coupler.

Insert the coupler as shown until it locks

into place.

Lower the cover (1), keeping the coupler

cable in the coupler cable port (2).

5

Connect the power cord.

Insert one end of the power cord into the

compact power adapter, and then plug

the other end into a power outlet.

Turn the camera on and use it as desired.

When finished, turn the camera off and

unplug the power cord from the outlet.

Do not disconnect the adapter or unplug the power cord while
the camera is still on. This may erase your shots or damage the
camera.

Do not attach the adapter or adapter cord to other objects.
Doing so could result in malfunction or damage to the product.

(1)

(2)
