GB

45

[Wireless LAN]

Supported format: IEEE 802.11 b/g/n
Frequency band: 2.4 GHz
Supported security protocols: WEP/

WPA-PSK/WPA2-PSK

Configuration method: Wi-Fi Protected

Setup (WPS)/Manual

Access method: Infrastructure mode
NFC: NFC Forum Type 3 Tag-

compliant

Model No. WW906746

AC Adaptor AC-UUD12/UUE12

Power requirements: AC 100 V to

240 V, 50 Hz/60 Hz, 0.2 A

Output voltage: DC 5 V, 1.5 A

Rechargeable battery pack
NP-FW50

Battery type: Lithium-ion battery
Maximum voltage: DC 8.4 V
Nominal voltage: DC 7.2 V
Maximum charge voltage: DC 8.4 V
Maximum charge current: 1.02 A
Capacity: 7.3 Wh (1 020 mAh)

Lens E PZ 16 – 50 mm F3.5 –
5.6 OSS*

1

(supplied with

ILCE-6300L)

Equivalent 35 mm-format focal

length

*2

: 24 mm – 75 mm

Lens groups – elements: 8 – 9
Angle of view

*2

: 83° – 32°

Minimum focus

*3

: 0.25 m – 0.3 m

(0.82 feet – 1 feet)

Maximum magnification: 0.215×
Minimum aperture: f/22 – f/36
Filter diameter: 40.5 mm
Dimensions (max. diameter × height):

Approx. 64.7 mm × 29.9 mm
(2 5/8 in. × 1 3/16 in.)

Mass: Approx. 116 g (4.1 oz.)
SteadyShot: Available

*1

Power zoom lens

*2

The values for equivalent 35 mm-
format focal length and angle of
view are based on digital cameras
equipped with an APS-C sized
image sensor.

*3

Minimum focus is the shortest
distance from the image sensor to the
subject.

Design and specifications are subject
to change without notice.

On focal length

The picture angle of this camera is
narrower than that of a 35 mm-format
camera. You can find the approximate
equivalent of the focal length of a
35 mm-format camera, and shoot with
the same picture angle, by increasing
the focal length of your lens by half.
For example, by using a 50 mm lens,
you can get the approximate equivalent
of a 75 mm lens of a 35 mm-format
camera.
