FOOT PEDAL LINKAGE PARTS LIST
REF# PART# DESCRIPTION QUANTITY
24 10-150 Battery Hold Down 1
HN-14-20 Nut 1 /
4
- 20 1
25 10-195 Hood Rod 1
HW-516 Washer 5 /
16
2
HP-18-100 Cotter Pin 1 /
8
x 1 2
26 8929-26 Seat Hinge 1
HST-14-20-075 Truss Head Machine Screw 1 /
4
- 20 x 3 /
4
6
HW-14 Washer 1 /
4
6
HWL-14 Lock Washer 1 /
4
6
HN-14-20 Nut 1 /
4
- 20 6
27 10-211 Hood Rod Mount 1
HST-14-20-075 Truss Head Machine Screw 1 /
4
- 20 x 3 /
4
2
HWL-14 Lock Washer 1 /
4
2
HN-14-20 Nut 1 /
4
- 20 2
28 HB-38-16-350 Bolt 3 /
8
- 16 x 3 1 /
2
1
HNTL-38-16 Lock Nut 3 /
8
-16 1
29 34-162 Throttle Bracket 1
HSM-10-32-063 Machine Screw #10 - 32 x 5 /
8
4
HWL-10 Lock Washer #10 4
HN-10-32 Nut #10 - 32 4
30 HST-14-20-075 Truss Head Machine Screw 1 /
4
- 20 x 3 /
4
2
HWL-14 Lock Washer 1 /
4
2
HN-14-20 Nut 1 /
4
- 20 2
