46 Owner’s Manual
KIT Setting Area
(KIT)
This section describes the KIT setting area, which can be accessed using the [KIT] button. Your DTX-MULTI 12 is pre-
loaded with a rich selection of Preset kits (P001 to P050) for immediate use, and you can also create and save up to
200 of your own drum kits as User kits (U001 to U200). Use the KIT setting area to select and edit these drum kits.
Makeup of KIT Setting Area
The KIT setting area is subdivided into eight different sections (KIT1 to KIT8). Use the [ B ]/[ C ] buttons to navigate between these sec-
tions. If a section contains parameter-setting pages, the [ENTER] button will light up. Press the [ENTER] button to access these pages. In
certain cases, a number of additional pages may be accessed from a parameter setting page, also using the lit [ENTER] button. Furthermore,
you can press the [EXIT] button to move back towards the top of the setting area.
• Be sure to store any settings that you have edited before turning off the instrument or selecting a new kit. (See page 45.)
CAUTION
KIT1
P001:PercsMaster
KIT2≥≥≥≥≥≥≥≥≥≥≥≥
≥≥≥≥≥COMMON≥≥≥≥≥
KIT3
≥≥EFFECT≥SEND
KIT4
≥≥≥VARIATION
KIT5
≥≥≥≥≥CHORUS
KIT6
≥≥≥≥≥REVERB
KIT7
≥≥≥≥≥OTHER
KIT8≥≥≥≥≥≥≥≥≥≥≥≥
≥≥≥≥≥≥JOB≥
Select Kit ......................................................................................................... Page 47
KIT4-1 Variation Type page ............................................................................. Page 48
KIT4-2 Variation Return page.......................................................................... Page 49
KIT4-3 Variation Pan page .............................................................................. Page 49
KIT4-4 Variation to Reverb page ..................................................................... Page 49
KIT4-5 Variation to Chorus page ..................................................................... Page 49
KIT2-1 Kit Volume page .................................................................................. Page 47
KIT2-2 Kit Selection Tempo page.................................................................... Page 47
KIT2-3 Kit Name page..................................................................................... Page 47
KIT3-1 Chorus Send page .............................................................................. Page 48
KIT3-2 Reverb Send page............................................................................... Page 48
KIT5-1 Chorus Type page ............................................................................... Page 49
KIT5-2 Chorus Return page............................................................................ Page 49
KIT5-3 Chorus Pan page ................................................................................ Page 50
KIT5-4 Chorus to Reverb page ....................................................................... Page 50
KIT6-1 Reverb Type page................................................................................ Page 50
KIT6-2 Reverb Return page ............................................................................ Page 50
KIT6-3 Reverb Pan page................................................................................. Page 50
KIT7-1 Layer Switch page ............................................................................... Page 51
KIT7-2 Mute Switch page................................................................................ Page 51
KIT7-3 Hi-hat Function page ........................................................................... Page 52
KIT7-4 Hi-hat MIDI Channel page................................................................... Page 52
KIT7-5 Hi-hat MIDI Type page......................................................................... Page 52
KIT7-6 Trigger Setup Link page ...................................................................... Page 52
KIT8-1 Copy Pad page.................................................................................... Page 53
KIT8-2 Exchange Pads page .......................................................................... Page 53
KIT8-3 Exchange Kits page ............................................................................ Page 54
KIT8-4 Initialize Pad page ............................................................................... Page 54
KIT8-5 Initialize Kit page ................................................................................. Page 54
Sections Parameter-setting pages
