VOICE Setting Area (VCE)
Owner’s Manual
59
D
Resonance (Q)
Use this parameter to change the timbre of the voice by boost-
ing frequencies around the cutoff frequency.
Effect Send Levels
In the EFFECT SEND section, you can adjust the degree to which
the DTX-MULTI 12’s built-in Variation, Chorus, and Reverb
effects are applied to individual voices. With the EFFECT SEND
page (VCE4) displayed, press the [ENTER] button to access its
three parameter-setting pages (VCE4-1 to VCE4-3). You can use
the [
B
]/[
C
] buttons to navigate between these pages.
1
Pad number
B
Layer number
C
Variation send level (Var)
Use this parameter to specify how much of the sound pro-
duced by the layer indicated by
2
will be sent to the Variation
effect.
1
Pad number
B
Layer number
C
Chorus send level (ChoSend)
Use this parameter to specify how much of the sound pro-
duced by the layer indicated by
2
will be sent to the Chorus
effect.
• The chorus send level for the entire kit can be adjusted on the KIT
area’s Chorus Send page (KIT3-1).
1
Pad number
B
Layer number
C
Reverb send level (RevSend)
Use this parameter to specify how much of the sound pro-
duced by the layer indicated by
2
will be sent to the Reverb
effect.
• The reverb send level for the entire kit can be adjusted on the KIT
area’s Reverb Send page (KIT3-2).
Settings
-64 to +0 to +63
VCE4 EFFECT SEND
VCE4-1
Variation Send page
Settings
01 to 12, 13, 13R1, 13R2, 14 to 17, FTSW,
HHCL, HHSP, C#-1, or D-1 to A#5
Settings
A, B, C, or D
Settings
0 to 127
Resonance (Q)
Frequency
Cutoff frequency
Level
VCE4
≥≥EFFECT≥SEND
VCE4-1≥-º¡-≥≥≥≥ç
Var=127(Dry=≥≥0)
3
1
2
VCE4-2
Chorus Send page
Settings
01 to 12, 13, 13R1, 13R2, 14 to 17, FTSW,
HHCL, HHSP, C#-1, or D-1 to A#5
Settings
A, B, C, or D
Settings
0 to 127
VCE4-3
Reverb Send page
Settings
01 to 12, 13, 13R1, 13R2, 14 to 17, FTSW,
HHCL, HHSP, C#-1, or D-1 to A#5
Settings
A, B, C, or D
Settings
0 to 127
VCE4-2≥-º¡-≥≥≥≥ç
≥≥ChoSend=127
3
1
2
NOTE
VCE4-3≥-º¡-≥≥≥≥ç
≥≥RevSend=≥50
3
1
2
NOTE
