Onkyo TX-NR6100 7.2-Channel Network A/V Receiver - Manual (Page 110)

110
Setup Setup
2. Speaker 2. Speaker
„
1. Configuration
Change the settings of connection environment of the speakers.
‰ Speaker Channels (Default Value: 7.1 ch)
Select "2.1 ch", "3.1 ch", "4.1 ch", "5.1 ch", "6.1 ch", "7.1 ch", "2.1.2 ch", "3.1.2
ch", "4.1.2 ch", or "5.1.2 ch" to suit the number of speaker channels connected.
‰ Subwoofer (Default Value: Yes)
Set whether a subwoofer is connected or not.
Yes When a subwoofer is connected
No When a subwoofer is not connected
‰ Height Speaker (Default Value: Top Middle)
Set the speaker type if height speakers are connected. Select "Top Middle",
"Top Rear", "Rear High", "Dolby Speaker (Front)", "Dolby Speaker (Surr)",
"Front High" or "Top Front" according to the type and layout of the connected
speakers.
• If an item cannot be selected even though connection is correct, check
that the settings in "Speaker Channels" matches the number of connected
channels.
‰ Zone Speaker (Default Value: No)
Set the connection of speakers to Zone 2 speaker terminals.
• This setting cannot be selected when "Zone 2 Lineout" is set to an item other
than "Zone 2".
Zone 2 When speakers are connected to Zone 2 speaker terminals
No When speakers are not connected to Zone 2 speaker terminals
‰ Zone 2 Lineout (Default Value: Zone 2)
Set an output destination of the audio output from ZONE 2 LINE OUT/ZONE B
LINE OUT jack.
• This setting is fixed to "Zone 2" when "Zone Speaker" is set to "Zone 2".
Zone 2 When connecting an integrated amplifier in a separate room
(ZONE 2)
Zone B When connecting an integrated amplifier, transmitter of
wireless headphones, etc. to ZONE B
Front When connecting a power amplifier (European, Australian and
Asian models)
‰ Bi-Amp (Default Value: No)
Set whether the front speakers are bi-amp connected.
• This setting cannot be selected when surround back speakers or height
speakers (4.1.2 ch, 5.1.2 ch) are installed.
No When front speakers are not bi-amp connected
• This setting is fixed to "No" if "Zone Speaker" is set to "Zone
2".
Yes When front speakers are bi-amp connected
‰ Speaker Impedance (Default Value: 6 ohms or above)
Set the impedance (Ω) of the connected speakers.
• For impedance, check the indications on the back of the speakers or their
instruction manual.
4ohms When any of the connected speakers have 4 Ω or more to less
than 6 Ω impedance
6 ohms or above When all the connected speakers have an impedance of 6 Ω
or more
