From the rugged exterior styling to the bountiful amenities, every
No Boundaries vehicle is equipped to help you enter the next
territory. In order to help you fully appreciate the countless
features of your new Explorer, we invite you to explore this easy
to use Quick Reference Guide. Using the image of the instrument
panel located in the center of the guide, locate the feature you
would like to learn more about. Each numbered feature is briefly
described to the left of the instrument panel image. For more
information, please consult your Owner’s Guide.
This vehicle handles differently from an
ordinary passenger car in driving condi-
tions which may occur on streets and
highways and off-road. DRIVE WITH CARE
AND WEAR A SAFETY BELT AT ALL TIMES. Ford urges you to read
the Owner’s Guide and Driving Your SUV or Truck Supplement for
further information on safe driving precautions and instructions.
Headlamp and
Panel Dimmer
Control
2
3
Headlamp and Panel Dimmer Control
Rotate clockwise
to the first
position to turn
on the parking
lamps. Rotate to
the second position to also turn on the
headlamps. Rotate counterclockwise to
activate autolamp (if equipped), which
provides light-sensitive automatic on-off
control of the exterior lights.
When the control is in any position except
high beams or off, pull the control toward
you to activate the foglamps (if equipped).
Use the instrument panel dimmer
control, which is located to the right of
the headlamp control, to adjust the
brightness of the instrument panel during
headlamp and parking lamp operation.
Turn Signal and Wiper/Washer Control
For front wiper operation, rotate the
ring on the left to the desired interval,
low- or high-speed position. When in the
intermittent position, rotate the control
up for fast or down for slow intervals. In
addition, the speed-sensitive front wipers
automatically adjust as the vehicle’s
speed changes when the control is set
for intermittent operation. Push the end
of the stalk briefly for a single wipe
(no wash). Push and hold for three
swipes with wash. The ring on the right
operates the rear window wiper. Rotate the
control to the normal speed (INT 2),
intermittent (INT 1), or washer position.
ABS Warning Lamp
Your anti-lock braking system (ABS)
detects the onset of wheel lockup
during brake applications and helps
prevent wheels from locking during
extreme braking situations. The ABS
warning light will illuminate when you start
your engine; however, if it stays on, continues
to flash or fails to illuminate, see your dealer-
ship's service department immediately.
Tire Pressure Warning Lamp
(if equipped)
See Additional Features for details.
Hazard Flasher Control
Press to activate all hazard flashers
simultaneously in an emergency to warn
traffic of vehicle breakdown, approaching
danger, etc. Press the control again to turn
the flashers off. The hazard flashers can be
operated when the ignition is off.
Service Engine Soon Lamp
Illuminates briefly to ensure the
system is functional. If it illumi-
nates while driving, it can mean
that one of the engine’s emission
systems has failed or that your fuel
cap is not properly installed.
A loose fuel cap can cause the “Check Fuel
Cap” lamp to illuminate or create a “Check Fuel
Cap” warning message in the optional message
center. These warnings reset once the cap is
tightened and your vehicle is driven a short
distance. To prevent activation of these
systems, always secure your fuel cap by turning
it clockwise 1/8 of a turn until it stops.
Gearshift/Overdrive Control
Overdrive is the normal drive position for the
best fuel economy. Only deactivate (O/D OFF)
overdrive when: driving with a heavy load,
towing a trailer up or down steep hills, or
when additional engine braking is desired.
To deactivate, press the switch located on
the end of the gearshift lever. When the
battery is disconnected or a new battery is
installed, the engine must relearn its idle and
fuel trim strategy. Therefore, the transmission
2
3
4
6
5
7
Turn Signal and
Wiper/Washer
Control
Service Engine
Soon Lamp
ABS Warning
Lamp
6
Hazard
Flasher Control
5
Tire Pressure
Warning Lamp
(if equipped)
Gearshift/
Overdrive
Control
10
11
Audio
Systems
12
Control Trac
Four-Wheel
Drive Control
(if equipped)
14
Power Adjustable
Foot Pedals
(if equipped)
Reverse Sensing
System (RSS)
(if equipped)
Brake
Release 13
Climate
Control
System
(if equipped)
may shift firmly. This is considered normal
and will not affect function or durability.
For more information, please consult your
Owner’s Guide.
Message Center (if equipped)
Please see Additional Features for more details.
Premium Cassette/Single CD Radio
(if equipped)
Please see reverse side for more details.
In Dash Six CD Radio (if equipped)
Please see reverse side for more details.
Control Trac Four-Wheel Drive Control
(if equipped)
4X4 Auto automatically delivers full
power to the rear axle and to the
front axle as required for increased
traction. This is appropriate for
normal on-road driving. 4X4 High
provides four-wheel drive with
full power to all four wheels. 4X4
Low provides four-wheel drive
with full power to both axles
and includes a lower gear ratio
for low speed. 4X4 High and 4X4
Low should not be used on dry or merely
wet pavement.
To shift between 4X4 Auto and 4X4 High,
press either button at a stop, or while
driving at any speed. To shift to and from
4X4 Low, bring the vehicle to a stop and
keep the brake pedal depressed. Next, place
the gearshift in N (Neutral), then press
the 4X4 Low control, or press 4X4 Auto or
4X4 High if you are in the 4X4 Low mode.
When shifting from one four-wheel drive
position to the next, a mechanical noise
may be heard. This is normal and no service
should be required.
Automatic Dual
Climate Control System
(if equipped)
Please see reverse side for more details.
Power Adjustable Foot Pedals
(if equipped)
Press and hold the rocker control to
adjust the accelerator and brake
pedal toward you or away from you.
Adjust the pedals only when the
vehicle is stopped and the gearshift
lever is in the P (Park) position.
Speed Control
To operate, the speed control
must be ON and the vehicle’s
speed must be at or above
48 km/h (30 mph). To set a
speed, press SET +. To set a
higher speed, press SET + again.
To set a lower speed, press CST -.
Pressing RES will return to a previ-
ously set speed. To turn the speed
control off, press OFF, or depress the
brake pedal to disengage.
Reverse Sensing System (RSS)
(if equipped)
The RSS sounds a tone to warn the driver of
obstacles near the rear bumper when the R
(Reverse) gear is selected. The system detects
obstacles within approximately 2 meters
(6 ft.) behind the rear bumper, or near the
rear periphery, while the vehicle moves in
reverse at speeds less than 5 km/h (3 mph).
The system defaults to ON, but the RSS
control allows you to disable the system
when the ignition is ON, and the gearshift is
in R (Reverse).
The RSS may not detect small objects,
particularly those close to the ground. The
system may also operate incorrectly under
inclement weather conditions, especially if
the rear bumper sensors are covered with
dirt, snow, or ice.
Brake Release
Pull the release lever (rearward) to release
the parking brake. To set the parking brake,
press the parking brake pedal down until the
pedal stops. The BRAKE warning lamp in the
instrument cluster will illuminate (when the
ignition is turned ON).
9
10
11
12
13
16
Remote Entry System
Press this control
once to unlock the
driver’s door, and
twice to unlock all
doors and liftgate.
The optional
memory seat and power mem-
ory pedals will automatically move to
the desired memory position when
this control is pressed once. Please
consult your Owner’s Guide for
complete details on activating/
deactivating.
Press this control once to lock all
doors and liftgate. Pressing the
control a second time will chirp the
horn and flash the lights to confirm
that all doors are closed and locked.
Press this control to unlatch the
liftgate window.
Press this control to activate the
panic alarm. To deactivate, press the
control again, or turn the ignition
to ACC or ON.
Please note: When the key is removed from
the ignition, the easy entry/exit feature (if
equipped) automatically moves the driver’s
seat backwards slightly (if room is available).
It will automatically move the seat forward
to the original position when the key is
inserted into the ignition.
AdvanceTrac TM System (if equipped)
By monitoring vehicle speed,
yaw, lateral acceleration,
and intended direction, the
AdvanceTrac™ system provides
enhanced traction and stability
on slippery surfaces, or in emergency
maneuvers. The system defaults to on;
however, if equipped with four-wheel drive,
the stability control does not function in 4L.
If your vehicle should become stuck, try
switching the system off by pressing the
AdvanceTrac™ button on the center con-
sole. When the system is functioning, a yel-
low icon will flash.
Message Center (if equipped)
The message center displays
important vehicle information
through a constant monitor of
vehicle systems (with the
ignition in the ON position).
The system will notify you of
potential vehicle problems with
a display of system warnings
followed by a long indicator
chime. You may select display
features on the message center
by pressing the INFO or SETUP
button. The RESET button may be used
to reset select functions in the Info and
Setup menus.
For complete details on the message
center display features, please consult
your Owner’s Guide.
Tire Pressure Monitoring System
(if equipped)
Using radio-frequency pressure sensors, this
system monitors tire pressure on all road
tires and provides the driver with a yellow
warning light when air needs to be added.
Message Center equipped vehicles provide
additional warning messages.
Please note: Outside temperature affects
tire pressure. See your Owner’s Guide.
HomeLink® Universal Transceiver (if
equipped)
This three-button control, located on the
overhead console, is a convenient way to
replace up to three hand-held transmitters.
For more information, please consult your
Owner’s Guide.
8
14
15
1
8
Message
Center
(if equipped)
17
16
15
7
4
Speed
Control
9
17
warning
