Samsung SW52ASP User Manual
Page 6
5
CLEANING THE FILTER NET
1. Push the upper part of
the filter and pull in.
2. Open the cover as
shown in the figure.
3. Clean the filter.
4. Close the cover and insert the lower
part of the filter in the basket first and
then push the filter with "click" sound .
HOW TO ADD THE FABRIC SOFTENER
When a proper amount (one time does) of
fabric softener is stored in the softener inlet,it is
automatically put in at the last rinsing cycle.
Do not use detergent, bleach or starch into the
Softener Inlet.
Using too much softener may produce
unsatisfactory results.
Do not open the lid during the Spin Dry cycle.
If added too early, its effectiveness will decrease.
Do not leave the softener
into the Softener
Dispenser for a long time.
Because softner
became stiff.
HOW TO PUT THE DETERGENT IN
1. Open the detergent box by pulling in the direction of the arrow as shown in the figure and then put the
powder detergent in the detergent box.
2. Put in one-time amount of detergent evenly so the detergent may not brim over the box.
Caution : If softener is stored over the above base line, it may flow down at any time.
CLEANING THE FILTER
(pump drained washer)
LEVELLING
1. Place a rag under washer filter not to wet the floor.
2. Turn the filter-cap to the left.
3. Take out the filter and remove any sludge.
4. Reassemble in reverse order.
• If the washer is not leveled with the ground, it makes the
machine tremble more or be out of order. So, make sure
that the washer is leveled properly.
SEE IF THE MACHINE IS PLACED LEVEL BY CHECKING
THE POSITION OF THE WASHING TUB.
Open the lid of the machine, pour water into the tub up
to the level just below the pulsator, and adjust the legs so
that the pulsator is positioned at the center of the water
as shown in the figure.
Place the machine more than
10cm away from the wall.
Adjust the legs on feet
for levelling .
Detergent Device
Put the detergent in proportion to water level
Loosen Lock
Water
