SPREADARC ™ OSCILLATOR K278-1
RECOMMENDED AUTOMATIC WELDING HEADS
NA-3, -4
See publication E9.10
NA-5 See publication E9.30
Power Feed ™ 10A See publication E9.165
RECOMMENDED OPTIONS
Control Cable Extension (14 Pin to 14 Pin MS-Type Connection)
10 ft. (3.0 m) K1797-10
25 ft. (7.6 m) K1797-25
50 ft. (15.2 m) K1797-50
100 ft. (30.4 m) K1797-100
TOTAL:
T H E L I N C O L N E L E C T R I C C O M PA N Y
22801 St. Clair Ave., Cleveland, OH 44117-1199 • 216.481.8100 • www.lincolnelectric.com
SPREADARC ™ OSCILLATOR ORDER FORM
PRODUCT DESCRIPTION ORDER NUMBER QUANTITY PRICE
C U S T O M E R A S S I S T A N C E P O L I C Y
The business of The Lincoln Electric Company is manufacturing and selling high quality welding equipment, consumables, and cutting equipment. Our challenge is to meet the
needs of our customers and to exceed their expectations. On occasion, purchasers may ask Lincoln Electric for advice or information about their use of our products. We respond
to our customers based on the best information in our possession at that time. Lincoln Electric is not in a position to warrant or guarantee such advice, and assumes no liability,
with respect to such information or advice. We expressly disclaim any warranty of any kind, including any warranty of fitness for any customer’s particular purpose, with respect to
such information or advice. As a matter of practical consideration, we also cannot assume any responsibility for updating or correcting any such information or advice once it has
been given, nor does the provision of information or advice create, expand or alter any warranty with respect to the sale of our products.
Lincoln Electric is a responsive manufacturer, but the selection and use of specific products sold by Lincoln Electric is solely within the control of, and remains the sole responsibility
of the customer. Many variables beyond the control of Lincoln Electric affect the results obtained in applying these types of fabrication methods and service requirements.
Subject to Change – This information is accurate to the best of our knowledge at the time of printing. Please refer to www.lincolnelectric.com for any updated information.
Key Controls
A ) Digital Display
B ) Adjust Switch
C ) Jog Switch
D ) Stop Button
E ) Start Button
F ) On/Off Switch
G ) Select Switch
H ) LED Mode Indicators
A
H
G
B
C
D E F
A CLOSER LOOK
CONTROL CABLE EXTENSION
Cable Type Description
Wire Feeder Control Cable Extension
K1797-10 - 10 ft. (3.0 m) (1) 14 PIN MS-Type connector
K1797-25 - 25 ft. (7.6 m)
K1797-50 - 50 ft. (15.2 m)
K1797-100 - 100 ft. (30.4 m)
(1) Included with unit.
Unit Includes
• Spreadarc Controller
• 115 VAC to 42 VAC Transformer Kit
• 10 ft. (3 m) control cable (14 PIN) (connects to power source).
