8 RTR0542 and RTR0550 Rotary Tillers 311-464M 5/21/13
Introduction
Table of Contents
Introduction
The parts on your Rotary Tiller have been specially
designed by Land Pride and should only be replaced with
genuine Land Pride parts. Contact a Land Pride dealer if
customer service or repair parts are required. Your Land
Pride dealer has trained personnel, repair parts, and
equipment needed to service the implement.
Serial Number
Model No. _____________Serial No. _______________
For quick reference and prompt service, record model
number and serial number in the spaces provided above
and again on warranty page 29. Always provide model
number and serial number when ordering parts and in all
correspondences with your Land Pride dealer. Refer to
Figure 1 for location of your serial number plate.
Serial Number Plate Location
Figure 1
Further Assistance
Your dealer wants you to be satisfied with your Rotary
Tiller. If for any reason you do not understand any part of
this manual or are not satisfied with the service received,
the following actions are suggested:
1. Discuss the matter with your dealership service
manager making sure that person is aware of any
problems you may have and has had the opportunity
to assist you.
2. If you are still not satisfied, seek out the owner or
general manager of the dealership, explain the
problem and request assistance.
3. For further assistance write to:
Land Pride
Service Department
P.O. Box 5060
Salina, KS 67402-5060
E-mail address
[email protected]
23777
Land Pride welcomes you to the growing family of new
product owners. This rotary tiller has been designed with
care and built by skilled workers using quality materials.
Proper assembly, maintenance, and safe operating
practices will help you get years of satisfactory use from
this machine.
Application
The RTR05 Series Reverse-Till Rotary Tillers are
designed and built by Land Pride to till soil for seedbed or
planting preparation. The RTR05 Series tillers are
adapted for tractors with 540 rpm PTO speed and
Category 0, Category I-Limited, and Category I 3-Point
hitch on tractors in the 17-25 HP range. The RTR05
Series are Quick-Hitch adaptable.
Reverse rotation tillers tend to achieve greater depth
penetration, moving, and pulverizing more soil in the
process, while burying residue as opposed to leaving it
on top. RTR05 Series Land Pride Tillers have
applications in homeowner landscaping, smaller
nurseries, gardens, smaller hobby farms, and medium
duty residential use.
See “Specifications & Capacities” on page 25 and
“Features & Benefits” on page 26 for additional
information and performance enhancing options.
Using This Manual
•
This Operator’s Manual is designed to help familiarize
you with safety, assembly, operation, adjustments,
troubleshooting, and maintenance. Read this manual
and follow the recommendations to help ensure safe
and efficient operation.
•
The information contained within this manual was
current at the time of printing. Some parts may change
slightly to assure you of the best performance.
•
To order a new Operator’s or Parts Manual contact
your authorized dealer. Manuals can also be
downloaded, free-of-charge from our website at
www.landpride.com.
Terminology
“Right” or “Left” as used in this manual is determined by
facing the direction the machine will operate while in use
unless otherwise stated.
Definitions
Owner Assistance
The Online Warranty Registration or Warranty
Registration card should be completed by the dealer at
the time of purchase. This information is necessary to
provide you with quality customer service.
IMPORTANT: A special point of information related
to the following topic. Land Pride’s intention is this
information must be read & noted before continuing.
NOTE: A special point of information that the
operator should be aware of before continuing.
