LN-23P Wire Feeder Order Form
Required Options
Magnum Self-Shielded
Gun
Rated 350 amps, 60% duty
cycle, 90° nozzle. For .068
through 5/64” (1.7 through
2.0 mm) Innershield wire.
Includes reduced speed
switch. 10 ft. (3.0m).
Order K345-10.
Magnum Self-Shielded
Gun
For lighter weight and easier
handling. Rated 250 amps,
60% duty cycle. For .068
through 5/64” (1.7 through
2.0 mm) Innershield wire.
Includes reduced speed
switch. 10 ft. (3.0m).
Order K355-10.
LN-23P Adapter Kit
Allows the LN-23P to be con-
nected to the power source,
but only one can be used at
a time. 115 AC input.
Order K350 - for Terminal
Strip connection.
Order K350-1 - for
14 Pin MS-type connection.
Power LN-23P Adapter
Source Kits Required
Pipeliner 200, SA-250, Classic II, Classic 300 K350-1 Adapter Kit
K632-1 Wire Feed Module
CV-300, CV-400, CV-655, DC-400, DC-600, K350-1 Adapter Kit
DC-655, Ranger 250, Ranger 305, Commander 300,
Commander 500
SAE-400, SAE-400 Weld ‘N Air K350 Adapter Kit
K385-1 CV Adapter
Power Sources and Adapters
LN-23P Wire Feeder K316-L
Required Options
LN-23P Adapter Kit: for Terminal Strip Connection K350
for 14 Pin MS-type Connection K350-1
Magnum Self-Shielded Gun - 350 Amps K345-10
Magnum Self-Shielded Gun - 250 Amps K355-10
Recommended Power Sources
CV-300 See publication E4.20
CV-400 See publication E4.30
CV-655 See publication E4.40
DC-400 See publication E5.20
DC-600 See publication E5.40
DC-655 See publication E5.46
Ranger 250 See publication E6.103
Ranger 305 See publication E6.117/E6.118
Pipeliner 200 with Wire Feed Module See publication E6.131/E6.132
SA-250 with Wire Feed Module See publication E6.160
Classic II with Wire Feed Module See publication E6.140
Classic 300 with Wire Feed Module See publication E6.155/E6.156
Commander 300 See publication E6.205
Commander 500 See publication E6.215
SAE-400 with CV Adapter See publication E6.180
SAE-400 Weld ‘N Air with CV Adapter See publication E6.185
TOTAL:
