EFX-1000
High-Fidelity Sound
The high-fidelity design features 24-bit/96 kHz A/D and D/A signal converters
along with a 32-bit DSP, allowing the addition of effects without lowering the
original sound quality. A signal bypass function has also been incorporated.
3 Band Beat Effector
• Beat effects [BPM mode]: The EFX-1000 is equipped with the
same automatic BPM counter/beat effector made popular by the
EFX-500, which allows effect processing on single selected bands
in sync with the track tempo (BPM), for greater expressive
possibilities than with conventional all-band effectors.
• Beat effects [RHYTHM mode]: This industry-first rhythm effector
lets you apply effects in sync with a rhythm you input yourself. With
the capability of a far wider range of unique effects compared to
previous beat effectors, you have the potential for a new level
of DJ performance.
Digital Jog Break Function
The jog dial allows real-time control of effect sounds. Up to eight seconds
of jog function can be stored in memory for automated replay. In addition to
single memory plaback there is a loop mode for stored jog motion playback.
When used in combination with the beat effector, up to 49 effects can
be created.
MIDI IN/OUT Function
External MIDI signals (control signals and timing clock signals) can be used
to control the effector and as a medium for using the effector to control a
sequencer or other MIDI component.
Digital Link Function
A variety of functions can be performed by using the dedicated digital link
cable to connect this unit to a Pioneer DJ mixer (DJM-1000) with digital link
support.
Digital IN/OUT
Equipped with digital IN/OUT connectors at 24-bit/96 kHz sampling, the
EFX-1000 allows for use in-studio track creation and other applications
where high sound quality is demanded.
For more information and streaming demo videos, visit
www.pioneerdj.com/gear_EFX1000
FEATURES
SPECIFICATIONS
Power Supply ...................................................................... AC 120V, 60Hz
Power Consumption ............................................................................ 16W
Operating Temperature .............................. +5°C to +35°C (+41°F to +95°F)
Relative Humidity ..................................... 5% to 85% (without condensation)
Weight ................................................................................................. 5.3lbs
External Dimensions .................. 12-19/32” (W) x 9-7/32” (D) x 3-31/32” (H)
Sampling Rate .....................................................................................96kHz
A/D, D/A Resolution ............................................................................ 24bits Frequency Characteristics ....................................................... 20Hz - 22kHz
S/N Ratio .............................................................................................. 83dB
Distortion .............................................................................................0.02%
Headroom ............................................................................................ 19dB
Input Level .................................................................–10dBV/+4dBu (22kW)
Output Level ....................... –10dBV/+4dBu (RCA 1 kW∂, Phone jacks: kW∂)
..................................................................... *–10 dBV/ +4 dBu is switchable
PIONEER CORPORATION
1-4-1 Meguro, MEGURO-KU, TOKYO 153-8654, JAPAN
TEL: 81-3-3495-5246•FAX: 81-3-3495-9827
PIONEER ELECTRONICS (USA), INC.
2265 East 220th Street, Long Beach, CA 90810, U.S.A.
TEL: 800-421-1404•FAX: 310-952-2990
PIONEER ELECTRONICS ASIACENTRE, PTE. LTD. (PAC Head Office)
253 Alexandra Road, #04-01, SINGAPORE 159936
TEL: 65-6427-1111
PIONEER EUROPE NV - MULTIMEDIA DIV. (PEE-London)
Pioneer House, Hollybush Hill, Stoke Poges Slough, SL2 4QP, UNITED KINGDOM
TEL: 44-1753-789-789
PIONEER CHINA HOLDINGS CO., LTD. (PCH)
18F New Hua Lian Mansion (West), 775 Huai Hai Zhong Road (M), Shanghai 200020, CHINA
TEL: 86-21-6431-4466
PIONEER HIGH FIDELITY TAIWAN CO., LTD. (PTC)
13th FL, No.44, Jhongshan N Road, Taipei City, 10448 TAIWAN
TEL: 886-2-2521-3588
PIONEER ELECTRONICS AUSTRALIA PTY. LTD. (PTY)
178-184 Boundary Road, Braeside, Victoria 3195, AUSTRALIA
TEL: 507-300-3900
PIONEER INTERNATIONAL LATIN AMERICA S.A. (PILASA)
Plaza Credicorp Bank, 14th Floor, Calle 50 No.120, Panama City 0816-01361, R.O., PANAMA
Tel: 507-300-3900
Features and specifications subject to change without notification.
