English | 31
Bosch Power Tools 1 619 929 J53 | (12.5.11)
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Leinfelden, 24.01.2011
Assembly
f Avoid unintentional starting of the machine. During as-
sembly and for all work on the machine, the power plug
must not be connected to the mains supply.
Delivery Scope
Please also observe the representation of the
delivery scope at the beginning of the operat-
ing instructions.
Before starting the operation of the machine
for the first time, check if all parts listed be-
low have been supplied:
– Table saw with mounted saw blade 26 and riving knife 25
– Angle stop 3
– Profile rail 28
– Fastening kit “profile rail” 40 (guide plate, knurled nut,
screw, washer)
– Parallel guide 10
– Auxiliary parallel guide 37
– “Auxiliary parallel guide” fastening kit 38 (3 fastening
screws, 3 washers, 3 wing nuts)
– Blade guard 6.x*
* depending on country version: 6.1/6.2
– Allen key 21
– Allen key 64
– Ring spanner 22
– Push stick 23
– Insert plate 24
– Extraction adapter 32
Note: Check the power tool for possible damage.
Before further use of the machine, check that all protective
devices are fully functional. Any lightly damaged parts must
be carefully checked to ensure flawless operation of the tool.
All parts must be properly mounted and all conditions fulfilled
that ensure faultless operation.
Damaged protective devices and parts must be immediately
replaced by an authorised service centre.
Mounting Individual Components
– Carefully remove all parts included in the delivery from
their packaging.
Remove all packaging material from the machine and the
accessories provided.
– Take care that the packaging material under the motor
block es removed.
The following product features are fastened directly to the
housing:
Push stick 23, ring spanner 22, allen key 21 and 64, parallel
guide 10, angle guide 3, extraction adapter 32, auxiliary par-
allel guide 37 with fastening kit 38, blade guard 6.x.
– Carefully remove these product features from their stor-
age locations.
Also see figures Y1–Y6.
Mounting the Insert Plate (see figure A)
– Hook insert plate 24 into the rear insert-plate notches 34
of the tool basin.
– Guide the insert plate down.
– Press on the insert plate until it engages at the front in the
tool basin.
The front side of the insert plate 24 must be flush with or
somewhat lower than the saw table; the rear side must be
flush with or somewhat above the saw table. (also see “Ad-
justing the Level of the Insert Plate”, page 36)
Mounting the Blade Guard* (see figure B)
* depending on country version
– Turn crank 19 clockwise to the stop, so that the saw blade
26 is in the highest possible position above the saw table.
– Pull the riving knife 25 upward to the stop.
– Insert the blade guard 6.x into the recess in riving knife 25.
– Tighten the clamping lever 8.1.
or
Tighten clamping screw 8.2 with Allen key 21.
– Adjust the blade guard according to the workpiece height.
When sawing, the blade guard must always face lightly
against the workpiece.
Note: Clamping lever 8.1 is indexed (adjustable), allowing it
to be set to an ergonomically favourable or space-saving posi-
tion.
With the clamping lever tightened, pull its lever away from the
blade guard, turn it to the desired position and allow it to en-
gage again.
Mounting the Parallel Guide (see figure C)
The parallel guide 10 can be positioned either left or right
from the saw blade.
– Loosen clamping handle 35 of parallel guide 10.
This releases V-guide 36.
– Firstly, mount the parallel guide via the V-guide in guide
groove 11 of the saw table. Now, position the parallel
guide into the front guide groove 2 of the saw table.
The parallel guide can now be moved to any position.
– To lock the parallel guide, press the clamping handle 35
down.
Mounting the Auxiliary Parallel Guide (see figure D)
When sawing narrow workpieces and bevel angles, the
auxiliary parallel guide 37 must be mounted to parallel guide
10.
The auxiliary parallel guide can be mounted left or right from
parallel guide 10, as required.
For assembly, use the “auxiliary parallel guide” fastening kit
38. (3 fastening screws, 3 washers, 3 wing nuts)
