KDL-52/46/40/37/32V5500
x-xxx-xxx-xx(x)
Addi
tiona
l Inf
o
rmati
o
n
Unit: cm
Figures in the above table may differ slightly depending on the installation.
The wall that the TV will be installed on should be capable of supporting a weight of at least four times that of
the TV. Refer to “Specifications” (page 21) for its weight.
TV installation dimensions table
Model Name
Display
dimensions
Screen
centre
dimension
Length for each mounting angle
Angle (0
°)
Angle (20
°)
A
B
C
D
E
F
G
H
KDL-52V58xx
126.2
82.2
3.9
47.8
16.9
40.7
77.8
51.5
KDL-52W58xx
126.2
82.3
3.9
47.8
16.9
40.9
77.8
51.5
KDL-46V58xx
112.3
72.3
8.4
47.1
15.0
35.8
68.5
50.2
KDL-46W58xx
112.3
72.5
8.4
47.1
15.0
35.9
68.6
50.3
KDL-40V58xx
98.7
63.6
12.2
46.3
14.7
32.8
60.4
49.3
KDL-40W58xx
98.7
63.8
12.2
46.3
14.7
33.0
60.4
49.3
KDL-37V58xx
91.7
60.0
14.0
46.3
14.5
31.4
57.0
49.3
KDL-37W58xx
91.7
60.2
14.0
46.3
14.5
31.6
57.0
49.3
KDL-32V58xx
79.8
53.6
17.2
46.3
14.3
29.1
51.1
49.2
KDL-32W58xx
79.8
53.7
17.2
46.3
14.3
29.2
51.1
49.2
Screen centre point
WARNING
