(5) LAND DIMENSION (Ref.)
PCB: GLASS EPOXY t＝1.6mm
(5)-1 LAND PATTERN DIMENSIONS
(STANDARD PATTERN)
Unit:mm
(5)-2 SUBSTRATE BENDING TEST BENDING TEST BOARD
Page-6/8
MSCD-0315-SERIES
MAG.LAYERS
R1.0
Part of silk screen
Land
3.6 1.2
1.2
3.5
