8 — English
UNpACkINg
This product requires assembly.

Carefully remove the product and any accessories from
the box. Make sure that all items listed in the packing list
are included.
WARNINg:
Do not use this product if any parts on the Packing List
are already assembled to your product when you unpack
it. Parts on this list are not assembled to the product by
the manufacturer and require customer installation. Use
of a product that may have been improperly assembled
could result in serious personal injury.
 Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
 Do not discard the packing material until you have carefully
inspected and satisfactorily operated the product.
 If any parts are damaged or missing, please call
1-800-860-4050 for assistance.
pACkINg lIsT
String Trimmer
Adjustable Front Handle
Grass Deflector Assembly with Screws
Operator’s Manual
WARNINg:
If any parts are damaged or missing do not operate this
product until the parts are replaced. Use of this product
with damaged or missing parts could result in serious
personal injury.
Tools NEEDED
The following tool (not included) is needed for assembly:

Phillips Screwdriver
AssEMbly
WARNINg:
Do not attempt to modify this product or create
accessories not recommended for use with this product.
Any such alteration or modification is misuse and could
result in a hazardous condition leading to possible serious
personal injury.
WARNINg:
To prevent accidental starting that could cause serious
personal injury, always remove the battery pack or
unplug from the power source from the product when
assembling parts.
ATTAChINg gRAss DEFlECToR
See Figures 2 - 3.
WARNINg:
The line cut-off blade on the grass deflector is sharp.
Avoid contact with the blade. Failure to avoid contact
can result in serious personal injury.
 Remove the bag with screws from the grass deflector.
 Fit the grass deflector onto the trimmer head.
 Line up the screw holes in the grass deflector with the
holes in the trimmer head.
 Install supplied screws and tighten by turning clockwise
with a phillips screwdriver.
ATTAChINg ThE FRoNT hANDlE
See Figure 4.
 Loosen and remove the wing bolt from the handle.
 Install the handle on the rear handle pole in the area
indicated by the illustration.
 Adjust handle up or down, if necessary, to desired
operating position.
 Reinstall the wing bolt. Tighten wing bolt to secure.
