Operation
Operating Manual PSSu H FS SN SD(­T)(­R)
1001451­EN­08 26
8.2.6 5V, 24V
The "5 V" LED shows the status of the module supply.
Colour Status Meaning
­ ­ ­ No supply voltage for module supply or supply voltage is
faulty
Green Module supply is available on the module bus
The "24 V" LED shows the status of the periphery supply.
Colour Status Meaning
­ ­ ­ No supply voltage for periphery supply or supply voltage is
faulty
Green Periphery supply is available on the module bus
