399
4-3. Do-it-yourself maintenance
4
Mainten
ance an
d ca
re
6 AM2-2 7.5 A Starting system
7 EFI NO.1 10 A
Multiport fuel injection system/
sequential multiport fuel injection
system
8 EFI NO.2 10 A
Multiport fuel injection system/
sequential multiport fuel injection
system
9 EFI NO.3 7.5 A No circuit
10 GROW 80 A No circuit
11 EPMS 60 A Electric power steering system
12 MAIN 80 A
HEAD MAIN, ECU-B2, ALT-S, STR
LOCK, DOME, ECU-B, RAD NO.1
fuses
13 ALT
120 A
*1
ABS 1, ABS 2, RDI
*3
, CDS
*3
,
FAN 1
*4
, AC INV, TOWING, HTR,
DEICER fuses
140 A
*2
ABS 1, ABS 2, FAN 1, FAN 2, AC
INV, TOWING, HTR, DEICER fuses
14 P/I 50 A EFI MAIN, HORN, A/F, fuses
15 ABS2 30 A
ABS, TRAC, VSC, AUTO LSD
function, downhill assist control
system, hill-start assist control sys-
tem
16 ABS1 50 A
ABS, TRAC, VSC, AUTO LSD
function, downhill assist control
system, hill-start assist control sys-
tem
17 EFI MAIN 20 A
Multiport fuel injection system/
sequential multiport fuel injection
system, EFI NO.1, EFI NO.2, fuses
18 HORN 10 A Horn
19 EDU 25 A No circuit
Fuse Ampere Circuit
