OUTPUT
COMMAND
ACTION
Output 3
cir 20
Output 3 select Input1
cir 21
Output 3 select Input2
cir 22
Output 3 select Input3
cir 23
Output 3 select Input4
cir 24
Output 3 select Input5
cir 25
Output 3 select Input6
cir 26
Output 3 select Input7
cir 27
Output 3 select Input8
OUTPUT
COMMAND
ACTION
Output 4
cir 30
Output 4 select Input1
cir 31
Output 4 select Input2
cir 32
Output 4 select Input3
cir 33
Output 4 select Input4
cir 34
Output 4 select Input5
cir 35
Output 4 select Input6
cir 36
Output 4 select Input7
cir 37
Output 4 select Input8
OUTPUT
COMMAND
ACTION
Output 5
cir 40
Output 5 select Input1
cir 41
Output 5 select Input2
cir 42
Output 5 select Input3
cir 43
Output 5 select Input4
cir 44
Output 5 select Input5
cir 45
Output 5 select Input6
cir 46
Output 5 select Input7
cir 47
Output 5 select Input8
