Operation Controls and Functions
4.1. Front Panel
1. Remote control sensor.
2. Power Switch & LED Indicator:
The LED will illuminate when the power is turned on.
3. Input Select/Indicators (A):
Press the “HDMI™ OUT A” button repeatedly to switch to your desired source, and the
LED will illuminate to indicate which input source is being selected, and routed to HDMI™
A display.
4. Input Select/Indicators (B):
Press the “HDMI™ OUT B” button repeatedly to switch to your desired source, and the
LED will illuminate to indicate which input source is being selected, and routed to HDMI™
B display.
1 2 3 4
POWER
HDMI OUT A
INPUT
2 1 3 4
HDMI OUT B
INPUT
2 1 3 4
