SPECIFICATIONS:
CONNECTION AND OPERATION:
Input Ports 1 x AV
2 x HDMI
1 x PAL TV tuner
Output Ports 1 x HDMI
5VDC/3.2A (110/240v universal)
Input Resolutions 480i/576i/480p/576p, 720p/1080i/1080p
Output Resolutions 720p; 1080p
ESD Protection Human body model: ± 8kV (air-gap discharge)
± 4kV (contact discharge)
Power Supply
Dimensions (inch)
162.6(W) x 164.5(D) x 33.5(H)
Weight (lb) 1.3lb
Power Consumption 2.3W
Operating Temperature 0°C ~ 40°C / 32°F~104°F
Storage Temperature -20 C ~60 C / -4°F~140°F
Relative Humidity
Silkscreen Color
Chassis Material 20~90% RH (non-condensing)
Black
Plastic
1. Connect all of your sources to the inputs of the HD590
2. Connect an HDMI cable from the output of the HD590 to one of the HDMI inputs on the TV.
3. Select the designed output resolution on the remote control
4. Select the desired input on the Remote Control.
