Menu Descriptions:
Menu Items Sub Menu Description
CONTRAST For contrast adjustment
BRIGHTNESS For brightness adjustment
EDID
EDID1.3 1080P 2CH Select EDID of the HDMI monitor to HDMI 1.3 1080P
video 2 channel audio
EDID1.3 1080P 6CH Select EDID of the HDMI monitor to HDMI 1.3 1080P
video 6 channel audio
EDID1.3 1080P 8CH Select EDID of the HDMI monitor to HDMI 1.3 1080P
video 8 channel audio
EDID1.2 1080P 2CH Select EDID of the HDMI monitor to HDMI 1.2 1080P
video 2 channel audio
EDID1.3 1080I 2CH Select EDID of the HDMI monitor to HDMI1.3 1080I
video 2 channel audio
EDID1.3 1080I 8CH Select EDID of the HDMI monitor to HDMI1.3 1080I
video 8 channel audio
EDID1.2 1080I 2CH Select EDID of the HDMI monitor to HDMI1.2 1080I
video 2 channel audio
EDID COPY To read EDID from the HDMI sink device and store to
this portable HDMI monitor
1. Mute (Mute or enable the audio)
2. Info (To display the information of the signal status V+/-)
3. Turn Volume up or down
4. Brightness +/- Increase or decrease brightness
5. Contrast +/- Increase or decrease contrast
6. EDID selection buttons to select different embedded EDID
mode.
7. EDID COPY
You can read EDID from any source and store it to a DIS7-HD
Note: When the monitor is displaying the signal from HDMI
source, this button will not function
REMOTE CONTROL
1
2
3
4
5
6
7
