Features
The AT-AV-HDSDI provides high quality 12-bit conversion between analog
YPbPr and composite inputs and SDI video digital output. The AT-AV-HDSDI
supports both SD-SDI and HD-SDI formats (SMPTE 259M, SMPTE 292M, and
SMPTE 296M), and also features 3 SMPTE compliant HD/SD-SDI outputs.
 Supported HD formats:
1080i @50/59.94/60Hz; 1035i @50/59.94/60Hz; 720p@50/59.94/60Hz ;
1080p@24/30Hz
Supported SD formats:
NTSC @59.94Hz; PAL @50Hz
 Excellent quality 12-bit A/D conversion
 3x HD/SD-SDI outputs
 Auto HD/SD-SDI detection
 Composite/YPbPr SD and HD input
 Equipped with 2 extra equalized loop-outs
 Easy installation
 External DIP switch configuration
