Atlona AT HDTX RSNET - Manual (Page 3)

3
Bandwidth frequency 10.2Gbps
Input Ports 1 x HDMI (female)
1 x Captive Screw (IR IN)
1 x Captive Screw (Bi-directional RS-232)
1 x Captive Screw (Power)
1 x Mini USB
Output Ports 1 x RJ45
1 x Captive Screw (IR OUT)
Resolution outputs Video: up to 4Kx2K
Vesa: up to 1920x1200
Dimensions (HxWxD) 1.46 x 5.08 x 3.94 (inch) or 38 x 127 x 102 (mm)
Weight 0.425lbs or 0.193kg
Temperature Operating: 32°F to 104°F or 0°C to 40°C
Storage: -4°F to 140°F or -20°C to 60°C
Power consumption 11.3W
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Introduction
Go the distance of up to 328ft (100m) at 4Kx2K with the Atlona HDBaseT Transmitter. With pass
through support of up to 4Kx2K, 1920x1200, IR, RS-232, bi-directional Ethernet, as well as Lossy
and Lossless audio signals over a single CAT cable, the HDTX-RSNET provides an affordable high
quality solution for your audio/video needs.
Package Contents
Features
• 1 x AT-HDTX-RSNET
• 1 x 24V/2.7A DC Power Supply
• 3 x Female Captive Screw Connector (2 pin: power, 3 pin: RS-232, and 5 pin: IR)
• 1 x Pair of Wall/Rack mount ears
• 1 x User Manual
• Extends IR, RS-232, Ethernet, and audio/visual content up to 328ft over a single CAT5e/6/7 cable
• Supports resolutions up to 4Kx2K (four times 1080p) or 1920x1200 on pass through
• IR ports for emitting and receiving IR control signals for use of IR remote controls and 3rd party
IR controllers
• Bi-directional Ethernet pass through
• Provides PoE (Power over category cable) to compatible receivers
• Lossy, and lossless multi-channel audio formats pass through (including Dolby TrueHD and
DTS-HD Master Audio)
• Full 3D pass through
• HDCP compliant
Specifications
