ADVANTAGE ™
antenna series
10
Operating Instructions:
For best reception, please consider the following
conditions:
1. Keep the antenna away from sources of interference,
including air conditioners, microwave ovens, hair
dryers, etc. These are all sources of strong electrical
interference, and can cause poor quality or total loss of
TV signals.
2. Install the antenna as high as possible, and preferably
with a clear path between the antenna and the TV
station transmitters. Trees, buildings, mountains, etc.,
can all impact the performance of any antenna.
Features and Technical Data for
the Digital Advantage Antenna Series
• Designed for reception of HD digital TV signals
• Frequency Range: 54-216, 470-700 MHz
• Impedance: 75Ω
• Gain:
CM-3016
Average Gain:
VHF Lo: 1.2 dB
VHF Hi: 7.9 dB
UHF: 7.7 dB
Number of Elements: 24
CM-3020
Average Gain:
VHF Lo: 3.6 dB
VHF Hi: 8.6 dB
UHF: 9.5 dB
Number of Elements: 50
CM-3018
Average Gain:
VHF Lo: 2.3 dB
VHF Hi: 8.2 dB
UHF: 8.4 dB
Number of Elements: 30
