User's manual K&F SEQUENZA 5 incl. accessories
KLING & FREITAG GMBH © 2015 Version 4.1 Page 50 of 88
For outdoor use, there
are optional rain covers
for the flying frame, the
bass speakers and the tops.
These covers serve as rain
protection for the rear flying
mechanics as well as for the
cables and plugs.
Warning
The array can potentially
swing out. For this reason,
only the setup crew may
be in front of or behind
the array during lifting.
Lift the array evenly and slowly into its operating position so that it cannot swing out during
lifting, then secure it. In doing this, make sure that chain hoists and lifting accessories do not
get caught. Make sure that the speaker cables do not get crimped or get caught.
9.5 Stacked Setup
SEQUENZA 5 W speakers may only be stacked on a flying frame, on a SEQUENZA 5 B speaker,
or with a SEQUENZA 5 VariMount adapter on a stand. If a SEQUENZA 5 W speaker is to
be mounted on a SEQUENZA 5 B speaker, a SEQUENZA 5 flying frame does not have to be
mounted as a support.
Please note that the speakers must be turned upside down for a stacked setup. In order to
avoid detracting from the speakers' appearance, the logos should be turned by 180° after
setup.
Warning
No matter which setup you use, you must always secure the array to prevent tipping and
falling. To ensure safety, you can either use the lying flying frame with the optional accessory
'outrigger' or secure the array – with or without the flying frame – with suitable anchoring
such as lashing straps.
We recommend using the optional accessory 'outrigger' that you can purchase from your
K&F dealer. They are easy to mount and reliably secure the standing array to prevent falling.
Before setup, ensure that the ground is firm and cannot give in under the load of the stacked
speakers.
Ensure that all accessories of the flying frame are fastened in their provided parking
positions.
