Controls, LEDs and Connectors
RTM-ATCA-F120-OPT Installation and Use (6806800G29D)
46
Two RJ-45 telecom clocking interfaces for inter-shelf clocking configurations
Serial interface for accessing the main blade’s CPU
3.2.2.1
Fabric Channel Uplinks
The RTM provides access to the following six Ethernet fabric channel uplink interfaces at its face
plate:
Four 10 Gigabit Ethernet uplink interfaces via SFP+ connectors
Two 1 Gigabit Ethernet interfaces via SFP connectors
Their location is shown in the following figure.
