The BG4CB and BG5CB is just as simple to use. Connect the
unit to the included 12Vdc power supply and push the Power
switch up. The green LED on the front of the unit lights up,
indicating power. The video output connectors and tone
connector (BG4 and BG4CB) are immediately active when the
unit is powered. The “Bars Black” switch allows the end-user to
select either Full Field Color Bars (up) or Black Burst (down). An
internal jumper labeled SW3 will allow the end-user to select
either NTSC (center to interior of unit) or PAL (center to exterior
of unit).
Video Outputs – The BG4 / BG5 and BG4CB / BG5CB come
standard with BNC connectors for composite video. If Y/C video
is required, we can convert one or all connectors to MiniDIN
(typical S-Video) connectors.
Audio Outputs - The BG4 and BG4CB come standard with a
RCA connector with stereo unbalance tone. Balanced tone with
a mini-XLR connector is available upon request.
Specifications
Size: 4.1W x 1.5H x 5.5D inches
BG4 and BG5
Power: 12Vdc @ < 400mA (120Vac 60Hz – 12Vdc adapter).
Video Outputs (composite): BNC; 1 Vp-p w/ 75 Ohms
(short circuit protected).
(S-Video): MiniDIN; 1 Vp-p w/ 75 Ohms
(short circuit protected)
Audio Output (BG4 only): RCA; 2 Vp-p 1kHz (+/- 200Hz)
mini-XLR (optional); Balanced
2 Vp-p 1kHz (+/- 200Hz)
BG4CB and BG5CB
Power: 12Vdc @ < 200mA (120Vac 60Hz / 240Vac 50Hz –
12Vdc power supply).
Video Outputs (composite): BNC; 1 Vp-p w/ 75 Ohms
(short circuit protected)
(S-Video): MiniDIN; 1 Vp-p w/ 75 Ohms
(short circuit protected)
Audio Output RCA; 2 Vp-p 1kHz (+/- 200Hz)
mini-XLR (optional); Balanced
2 Vp-p 1kHz (+/- 200Hz)
BG4 / BG5 & BG4CB / BG5CB Black Burst/Color Bar Generator 3
