Page 9 – Coloronix RGBW Modular Lighting Manual V.2.2
ColorRay Stand Alone Mode
For application not using DMX control, user can preprogram shows.
The fixture’s on board computer have been pre-configured with ColorRay programs. No additional
software or hardware is needed to access. Set the dip switch address for stand alone use (see table
below)
Dip Address Setting Function Speed
0 All Down Demo Mode: Red, Green, Blue, White n/a
742 2,3,6,7,8,10 Static Color: Warm White n/a
743 1,2,3,6,7,8,10 Static Color: Cool White n/a
744 4,6,7,8,10 Static Color: Red n/a
745 1,4,6,7,8,10 Static Color: Green n/a
746 2,4,6,7,8,10 Static Color: Light Blue n/a
747 1,2,4,6,7,8,10 Static Color: Dark Blue n/a
748 3,4,6,7,8,10 Static Color: Orange n/a
749 1,3,4,6,7,8,10 Static Color: Purple n/a
750 2,3,4,6,7,8,10 Static Color: Pink n/a
751 1,2,3,4,6,7,8,10 Static Color: Yellow n/a
752 5,6,7,8,10 Full Rainbow:
Full Color Fade, Repeat 0.5 seconds
753 1,5,6,7,8,10 Full Rainbow:
Full Color Fade, Repeat 5 seconds
754 2,5,6,7,8,10 Full Rainbow:
Full Color Fade, Repeat 5 minutes
755 1,2,5,6,7,8,10 Full Rainbow:
Full Color Fade, Repeat 30 minutes
756 3,5,6,7,8,10 Christmas Colors:
Red, Green, Repeat 0.5 seconds
757 1,3,5,6,7,8,10 Christmas Colors:
Red, Green, Repeat 5 seconds
758 2,3,5,6,7,8,10 Christmas Colors:
Red, Green, Repeat 5 minutes
759 1,2,3,5,6,7,8,10 Christmas Colors:
Red, Green, Repeat 30 minutes
760 4,5,6,7,8,10 Cool Blue:
Dark Blue, Sky Blue, Repeat 0.5 seconds
761 1,4,5,6,8,10 Cool Blue:
Dark Blue, Sky Blue, Repeat 5 seconds
762 2,4,5,6,7,8,10 Cool Blue:
Dark Blue, Sky Blue, Repeat 5 minutes
763 1,2,4,5,6,7,8,10 Cool Blue:
Dark Blue, Sky Blue, Repeat 30 minutes
764 3,4,5,6,7,8,10 Exotic Colors:
Orange, Turquoise, Neon Green, Fuchsia, Repeat 0.5 seconds
765 1,3,4,5,6,7,8,10 Exotic Colors:
Orange, Turquoise, Neon Green, Fuchsia, Repeat 5 seconds
766 2,3,4,5,6,7,8,10 Exotic Colors:
Orange, Turquoise, Neon Green, Fuchsia, Repeat 5 minutes
767 1,2,3,4,5,6,7,8,10 Exotic Colors:
Orange, Turquoise, Neon Green, Fuchsia, Repeat
30 minutes
ColorRay Remote Control
For remote control of the ColorRay setting, use SCC5-In-Wall Receiver and remote control. All
programs and static colors can be set via remote control.
