22

Cybex Owner’s Manual

Belt Adjustment

Tools Required

•

7/32” Wrench

•

Torque wrench (lbs-in)

Belt Adjustment

Action

Loose Belt

1. Using a 7/32” Allen wrench loose set screws.

2. Pull belt tight.

3. Secure belt in place with set screws.

4. Torque set screws to 300-350 lb-in.

5. Verify that the belt is moving smoothly and is routed straight from

the top pulley bracket to the to weight belt clamp
