Daktronics BA-1518 Generation IV Multi-Section Outdoor LED Scoreboard - Manual (Page 20)

3-6 Specifications
Model Number of
Sections Dimensions
(Height, Width,
Depth) Weight
Uncrated
(Crated) Digit Size
Digit Color Maximum
Wattage Power Amps
per Line
(Single
Phase) Driver
Number
and
Address
BA-3718 4 Total
2 Top
2 Bottom
H7’-0”, W28’-0”, D6”
(2134 mm, 8534
mm, 152 mm)
H3’-0”, W14’-0”, D6”
(2134 mm, 4267
mm, 152 mm)
H4’-0”, W14’-0”, D6”
(1219 mm, 4267
mm, 152 mm) 640 lb
(290 kg)
2 Crates
825 lb
(374 kg)
525 lb
(238 kg) ƒ Innings,
Runs, Hits
and Errors
15” (9381
mm)
ƒ All
Others
18” (457
mm)
-11: red
-21: amber
900 W 120 V AC 7.5 A A1 64
A2 65
A3 66
BA-3718
w/TNMC 4 Total
2 Top
2 Bottom H7’-0”, W28’-0”, D6”
(2134 mm, 8534
mm, 152 mm)
H3’-0”, W14’-0”, D6”
(914 mm, 4267 mm,
152 mm)
H4’-0”, W14’-0”, D6”
(1219 mm, 4267
mm, 152 mm) 720 lb
(327 kg)
2 Crates
746 lb
(338 kg)
468 lb
(212 kg) ƒ Innings,
Runs, Hits
and Errors
18” (457
mm)
ƒ All
Others
24” (610
mm)
-11: red
-21: amber
1200 W
(w/red
TNMC)
1200 W
(w/amber
TNMC) 120 V AC 10.0 A
10.0 A A1 64
A2 65
A3 66
