The overall configuration process can be divided into two phases:
Base Configuration – setting up the UMI for IP connectivity and console security
Operational Configuration – setting up the UMI and BNS node to enable users to make calls
between the BNS and IP networks
Actual command sequences will be presented in this section to illustrate the UMI and related
node configuration process. For node commands, the appropriate references are the Data
Networking Products Synchronous/Asynchronous Multiplexer Reference and Commands
Reference. Section 5 of this document should be used as the reference for UMI module
commands.
4.2 BASE
CONFIGURATION
This phase of the configuration process sets up the UMI for IP networking. This includes the
UMI’s IP address and subnet mask, the IP address of the gateway router, the IP address of an
SNMP manager (optional), and the IP address of a domain name server (optional). It also
includes setting up console-security parameters, i.e., an administrative login password and the
(optional) timeout for automatic console logoff. These aspects of the configuration will rarely need
to be changed once they are satisfactorily set up.
The following is an example of base configuration:
<UMI>
login passwd=initial
↵
User is Logged in UMI
<UMI>
chgpass old=initial new=secret confirm=secret
↵
Password Change Operation Succeeded.
<UMI>
rm
↵
Remove
MODULE removed from service.
<UMI>
local ipaddr=135.17.59.165 submask=255.255.255.0
↵
<UMI>
gateway ipaddr=135.17.59.1
↵
<UMI>
dns ipaddr1=135.17.59.6
↵
<UMI>
snmp ipaddr=135.17.59.7
↵
<UMI>
vfy mod
↵
Current Configuration:
DK Module Type ==> TN1015 (TRK-T1) w/Serial# 0.
Service State ==> Out of Service.
Local MAC Address ==> 0.96.29.2.52.22
Local IP Address ==> 135.17.59.165
Subnet Mask ==> 255.255.255.0
Gateway IP Address ==> 135.17.59.1
DNS Name Server Address ==> [#1] 135.17.59.6
SNMP Trap Manager ==> 135.17.59.7 Port 162
<UMI>
rs
↵
Restore
Module restored to service
Reboot Initiated to Make Physical Parameters effective.
