TST7600 with TMR Tracker
Page 48 TST7600 Touch Screen D3989-US Rev A
Cable Connections:
Connect to
serial/com 1-2
connection on
scale.
Battery power
connection.
(Must be fused)
Red (+); Black (-)
Connect cable to
serial power
connection A
Power cable
p/n: 408479
