Digi-Star John Deere 750/1560/1590- 15ft Drill User Manual
Page 11
Repair Parts
D3859-US-Rev A
John Deere 750/1560/1590-15 ft Grain Drill
9
KEY QTY. PART
NO. DESCRIPTION
1
1
405763
Weld – Front Brkt RH (JD750-15’)
2
1
405763
Weld – Front Brkt LH (JD750-15’)
3
1
405761
Weld – Rear Brkt RH (JD750-15’)
4
1
405760
Weld – Rear Brkt LH (JD750-15’)
5
2
405764
Weld – Middle Brkt (JD750-15’)
6
4
405854
SCR – 1/2-13 x 2-1/4 HHCS ZP Grd 5
7
8
405863
SCR – 5/8-11 x 8-1/2 HHCS ZP Grd 5
8
8
171610
Wash - 3/8 Flat Narrow ZP
9
4
405053
Wash – 1/2 Flat Wide ZP
10
16
405858
Wash – 5/8 Flat Wide ZP
11
4
406085
Nut – 1/2-13 Ser Flange ZP
12
8
406070
Nut – 5/8-11 Top-Lock Flange ZP
13
8
405859
Pin – Cotter 5/32 x 1.5 ZP
14
4
405861
Pin – Clevis 3/8 x 2.5 ZP
15
4
405860
Pin – Clevis 3/8 x 2.25 ZP
16
3
405862
Link – Offset #40
17
1
405838
Bar – 26.125” Clutch (JD1590750)
18
2
400400
Cell – 1.5 DB – 16FT
19
2
400373
Cell – 1.5 DB – 11FT
20
1
406232
J-Box Lever Nut 4PT (Planter)
21
1
141837
Cable – 30FT J-Box
22
1
405072
Cable – Power 6FT 2-Wire
23 1 405512 GT400
Indicator
