18
GREASE FILTER
Display percentage of utilisation:
- press button 3 until moving the indicator(b) on the “GREASE
FILTER” function
- press button 4 to display the percentage of utilisation of the grease
filter
Grease filter reset warning
The grease filter warning is displayed after 40 hours of utilisation
with the wording “RESET”(e) next to the “GREASE FILTER”
function
When this warning is displayed the grease filter must be washed.
After performing maintenance:
- press button 3 until moving the indicator(b) on the “GREASE
FILTER” function
- press button 4, for 5 seconds, to disable the warning and restart
the grease filter efficiency percentage counting.
ODOUR FILTER
Display percentage of utilisation:
- press button 3 until moving the indicator(b) on the “ODOUR
FILTER” function
- press button 4 to display the percentage of utilisation of the carbon
anti-odour filter
Carbon anti-odour filter reset warning
The carbon anti-odour filter warning is displayed after 160 hours of
utilisation with the wording “RESET”(f) next to the “ODOUR
FILTER” function
When this warning is displayed the carbon anti-odour filter must be
washed or replaced (depending on the model you have)
After performing maintenance:
- press button 3 until moving the indicator(b) on the “ODOUR
FILTER” function
- press button 4, for 5 seconds, to disable the warning and restart
the carbon anti-odour filter efficiency percentage counting.
Maintenance
ATTENTION! Before performing any maintenance operation,
isolate the hood from the electrical supply by switching off at the
connector and removing the connector fuse.
Or if the appliance has been connected through a plug and socket,
then the plug must be removed from the socket.
Cleaning
The cooker hood should be cleaned regularly (at least with the
same frequency with which you carry out maintenance of the fat
filters) internally and externally. Clean using the cloth dampened
with neutral liquid detergent. Do not use abrasive products. DO
NOT USE ALCOHOL!
WARNING: Failure to carry out the basic cleaning
recommendations of the cooker hood and replacement of the filters
may cause fire risks.
Therefore, we recommend observing these instructions.
The manufacturer declines all responsibility for any damage to the
motor or any fire damage linked to inappropriate maintenance or
failure to observe the above safety recommendations.
Grease filter
Fig. 12-33
Traps cooking grease particles.
This must be cleaned once a month (or when the filter
saturation indication system – if envisaged on the model in
possession – indicates this necessity) using non aggressive
detergents, either by hand or in the dishwasher, which must
be set to a low temperature and a short cycle.
When washed in a dishwasher, the grease filter may discolour
slightly, but this does not affect its filtering capacity.
To remove the grease filter, pull the spring release handle.
Charcoal filter (filter version only)
Fig. 32
It absorbs unpleasant odours caused by cooking.
The activated charcoal filter can be one of these types:
•
Washable activated charcoal filter.
• NON-washable activated charcoal filter.
Washable activated charcoal filter
The charcoal filter can be washed once every two months
using hot water and a suitable detergent, or in a dishwasher at
65°C (if the dishwasher is used, select the full cycle function
and leave dishes out).
Eliminate excess water without damaging the filter, then
remove the mattress located inside the plastic frame and put it
in the oven for 10 minutes at 100° C to dry completely.
Replace the mattress every 3 years and when the cloth is
damaged.
NON-washable activated charcoal filter
The saturation of the charcoal filter occurs after more or less
prolonged use, depending on the type of cooking and the
regularity of cleaning of the grease filter.
In any case it is necessary to replace the cartridge at least
every four mounths.
The charcoal filter may NOT be washed or regenerated.
Assembly
Hook the charcoal filter at the back on the metal tongue of the
hood first, then on the front with the two knobs.
Disassembly
Remove the charcoal filter by turning the knobs fixing it to the
hood by 90°.
Replacing lamps
The hood is equipped with a lighting system based on LED
technology.
The LEDs guarantee an optimum lighting, a duration up to 10
times as long as the traditional lamps and allow to save 90%
electrical energy.
For replacement, contact the technical service.
