Specifications
Power Supply Requirements
Connection to a 12 to24 V dc (UL listed) Class 2 power source ..................................... 600 mA minimum
Power consumed ............................................................................................................7 watts maximum
Auxiliary outputs.................................................... Sink 150 mA maximum, per output to circuit common
and pulled up to the power input voltage
Mechanical
Enclosure .................................................................Steel body and cover; black fine-textured paint finish
Mounting .............................................................................................................................. Wall or shelf
Dimensions ..........................................................7.50 W
× 5.625 D × 1.02 H inches (191 × 143 × 26 mm)
Weight ............................................................................................................................ 2 lbs. (0.902 kg)
Environmental
Temperature range................................................................................ +32º F to +122º F (0º C to +50º C)
Replacement Parts
Part Number Description
69407-002 PCBA, I/O Controller
