Power Connections
The power connections for all voltage options connect to the same MS connector on the top end of the
chassis. The power cord is not included. Refer to Figure 6 and Figure 7 for the respective models above.
CAUTION
Connect the power cable to the correct power source. Follow all the
appropriate National Electric Codes as well as local county and city electric codes.
Models 4514-001 and 4514-001FR
The black wire (pin A) is hot in the case of 110/220 V ac.
The white wire (pin B) is neutral or negative.
Models 4512-001 and 4512-001FR
The black wire (pin B) is positive in the case of 270 V dc.
The white wire (pin C) is negative.
Battery Connections
Install the GAI-Tronics 40201-004 Battery as follows. Refer to Figure 4 on page 7.
1. Loosen the mounting screw on the right of the 63069-013 Battery Bracket and lift it out of the
keyhole slot. Slide the battery into place. Replace the bracket and tighten the bracket screw.
2. The battery wire connections are parked on terminals TP1 and TP2 on the Power Supply PCBA.
3. Unplug the black wire from the Power Supply PCBA and slide onto (−) negative terminal of the
battery.
4. Unplug red wire from the Power Supply PCBA and slide onto (+) positive terminal of the battery.
N
OTE
: If the battery is already charged, a small spark may occur when connecting the red wire. This
is normal.
Microphone Connection
Select a Model MI2895 or similar microphone. Install the microphone by plugging it in using the
appropriate connector on the top of the radio. R36 is the microphone volume adjustment.
Speaker Connection
Select a Model 13354-001 or similar speaker. Install the speaker by plugging it into the appropriate
connector on the top of the radio.
WARNING
Do not ground any speaker line as damage may occur to the speaker and/or radio.
