ALC Control Module Specifications
Power input ...................................................................................... 24 V dc +/−20% @ 350 mA maximum
Physical size ................................................................................................... 4.0 W
13.5 L 3.0 D inches
Operating environment .................................................... 0º C to 50
C @ 95% humidity (non-condensing)
Paging input impedance ..................................................................... 100 k
, or jumper-selected 600 ohms
Paging audio I/O range .................................................................................................... −40 dBm to 0 dBm
Paging adjustment range ....................................................................................... −3 dB to -30 dB minimum
Emergency paging level .................................... Direct wire connection from input to output, no attenuation
Paging audio S/N ratio .................................................................................. 45 dB minimum, ref. to 0 dBm
Paging audio distortion .....................................................................................................Less than 1% THD
Output impedance .................................................................................... 100 ohms, electronically balanced
Monitor amp output ...................................................... 250
W maximum into a standard 30-ohm headset
Fuse Replacement
CAUTION
For continued safe operation, replace fuses with the same type:
F1 is a Bussman GMC 600 mA fuse.
N
OTE
: The Model 12604-014 Replacement Fuse Kit is available for all of the S.M.A.R.T. Modules. It
contains ten of each of the required sizes.
