Model 12578-003 Monitored Input Module (MIM)
Page 12 of 12
f:\standard ioms - current release\42004 instr. manuals\42004-715l2c.doc
06/12
Mechanical
Unit dimensions .................................... 4.00 H
10.50 W 1.25 D inches (101.60 266.70 31.75 mm)
Unit weight ....................................................................................................................... 1.00 lb. maximum
Environmental
Temperature range (operating/storage) .................................................. −30
C to 70 C (−22 F to 158 F)
Humidity .......................................................................................... 95% non-condensing relative humidity
Replacement Parts
Model No.
Description
69613-001 CPU
PCBA
69251-201
Monitored In-8 PCBA
Reference Material
REFERENCE TO ASSEMBLY/MODEL DRAWINGS
Published By
Title
GAI-Tronics Ref. No.
GAI-Tronics
Monitored Input Module Assembly Drawing
73567
