PAGE 27
OWNER'S MANUAL
ROC-IT WEIGHT CAGE ASSEMBLY
PART LIST
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED, AND ACTUAL WEIGHT
STACK COUNT MAY VARY. REFER TO MACHINE MANUAL FOR CORRECT QUANTITY.
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
1
026-01X2378
BOTTOM GUIDE ROD MOUNT
1
2
026-01X2411
BACK BONE ASSEMBLY
1
3
026-01X2453
TOP GUIDE ROD MOUNT
1
4
018-0001002
CABLE PULLEY:
3.50"
3
5
019-0001006
THICK RUBBER DONUT
3.00" X .50" BLACK
2
6
026-01G0193
GUIDE ROD
.750" X 49.078" LG.
2
7
026-01M1013
1.50" TOWEL HANGER
1
8
026-01PL0369
WEIGHT STAND OFF
2
9
026-01PL2122
OVAL-SHAPED RUBBER FOOT
2
10
026-01PL2127
TOP CAP
1
11
026-01PL2131
D-SHAPED RUBBER FOOT
1
12
026-01PL2153
PLASTIC SHIELD
1
13
026-1100212
SHIELD - RIGHT
1
14
026-1100213
SHIELD - LEFT
1
15
026-01X2872
8 LB TOP WEIGHT PLATE ASSEMBLY
1
16
026-01X2873
15 LB TOP WEIGHT PLATE ASSEMBLY
1
17
026-01X2874
40 LB TOP WEIGHT PLATE ASSEMBLY W/ 18 HOLE STEM
1
18
026-01PL0348
WEIGHT PLATE SPACER .563" THICK
24
19
026-01W0122
WEIGHT PLATE BUSHING
24
20
026-01W0312
15 LB INTERMEDIATE WEIGHT PLATE
7
21
026-01W0315
20 LB INTERMEDIATE WEIGHT PLATE
17
22
026-01PL2176
3.00" OD X
.781" ID X .813" THICK SPACER
2
23
011-0101121
1/4"-20UNC X.75" BHCS (WZ) w/ NYLON PATCH
4
24
011-0407022
3/8"-16UNC X 1.00" HHB (WZ)
2
25
011-0407027
3/8"-16UNC X 1.75" HHB (WZ)
4
26
011-0407058
3/8"-16UNC X 2.00" HHB (WZ)
2
27
011-0101041
3/8"-16UNC X .75" BHCS (WZ)
5
28
011-0101027
3/8"-16UNC X 1.50" BHCS (WZ)
1
29
012-0104008
3/8"-16 UNC THIN NYLOCK NUT (WZ)
6
30
013-0002003
1/4" X 16mm SAE FLAT WASHER (WZ)
4
31
013-0402007
3/8" X 22mm FLAT WASHER (WZ)
19
32
013-0702001
NYLON WASHER .38" I.D. X 1.00" O.D. X .06" THK
1
33
013-0102023
1/4" INTERNAL LOCK WASHER
4
34
013-0102020
3/8" SPLIT LOCK WASHER (WZ)
2
35
013-0102022
3/8" INTERNAL LOCK WASHER
5
36
021-0003573
COMMERCIAL MAINTENANCE DECAL
1
37
021-0003221
DECAL HOIST 2.50" X 9.13"
1
38
021-0003230
DECAL HOIST 1.63" X 5.93"
2
39
SERIAL # DECAL
DECAL SERIAL # 1.63" X 2.63"
1
40
021-0003344
ROC-IT WARNING DECAL
1
41
021-0003405
DECAL ROX
1
42
021-0003552
ROC-IT DOMED DECAL
1
43
021-0018022
DECAL HOISTFITNESS.COM LOGO
1
44
026-01X3036
30 LB TOP WEIGHT PLATE ASSEMBLY
1
45
026-01X2856
WEIGHT SELECTOR PIN
1
46
010-0008001
LANYARD COIL
1
47
026-01PL2200
PINETREE PLUG
1
48
026-01PL2201
PLASTIC SLEEVE
.75" O.D.
2
49
011-0112023
.473" X .281" SHSS (WZ)
2
50
021-0003571
ROC-IT RATIO DECAL
1
51
026-01X3137
8 LB TOP WEIGHT PLATE ASSEMBLY W/ 18 HOLE STEM
1
52
026-01X3140
15 LB TOP WEIGHT PLATE ASSEMBLY W/ 18 HOLE STEM
1
53
026-01X3141
30 LB TOP WEIGHT PLATE ASSEMBLY W/ 18 HOLE STEM
1
