ITEM NO. PART NUMBER DESCRIPTION QTY.
1 010-01C0608 CABLE ASSEMBLY: PEC FLY FLOATING PULLEY 34.8431" LG. 1
2 010-01C0609 CABLE ASSEMBLY: PEC FLY WEIGHT STACK 156.00" LG. 1
3 010-01C0610 CABLE ASSEMBLY: PEC FLY CAM 57.05" LG. 1
4 022-01PD2054-A SEAT PAD ASSEMBLY 1
5 022-01PD2055 UPHOLSTERED HEAD PAD 1
6 022-01PD2058 UPHOLSTERED BACK PAD 1
7 026-01X2359 ADJUSTABLE FLOATING PULLEY ASSEMBLY 4.50" 1
8 026-01X2387 SEAT PAD ASSEMBLY 1
9 026-01X2391 PULLEY GUARD ASSEMBLY Ø4.50" 2
10 026-01X2402 FOOT PLATE ASSEMBLY 2
11 026-01X5190 BASE FRAME ASSEMBLY 1
12 026-01X2775 MAIN ASSEMBLY 1
13 026-01X5191 ARM MOUNT ASSEMBLY 1
14 026-01X2840 CROSS MEMBER ASSEMBLY 1
15 026-01X2841 CROSS BAR ASSEMBLY 1
16 026-01X2849 RACHET PULL-PIN ASSEMBLY 1
17 026-01X2975 FOOT PLATE MOUNT ASSEMBLY 2
18 026-01X3338 HANDLE YOKE ASSEMBLY 2
19 026-01X5131 HANDLE LINK ASSEMBLY (LEFT) 1
20 026-01X5132 HANDLE LINK ASSEMBLY (RIGHT) 1
21 026-01X5135 PEC ARM ASSEMBLY (RIGHT) 1
22 026-01X5136 PEC ARM ASSEMBLY (LEFT) 1
23 026-01X5137 PULLEY V-MOUNT ASSEMBLY Ø4.50" 1
24 014-0005001 BEARING: (SMALL) Ø1.37" O.D. X Ø.75" I.D. 4
25 014-0009007 BEARING: FLANGE BEARING Ø2.00" O.D. X Ø1.00" I.D. 10
26 014-0101020 BUSHING: OILITE FLANGE Ø.63" O.D. X Ø.38" I.D. X .50" LG. 4
27 014-0104004 BUSHING: SLEEVE, BRONZE Ø.52" O.D. X Ø.31" I.D. X .59" LG. 3
28 016-0001003 END CAP 1.50" X 2.50" (BLACK) 1
29 018-0001003 CABLE PULLEY: 4.50" 8
30 018-0002012 WIDE GROOVE PULLEY 4.50" 2
31 019-0001001 PLUG BUMPER 2
32 019-0001003 BUMPER (BLACK) Ø1.50" O.D. X Ø.75" I.D. X .63" LG. 4
34 022-01PD2055-5 PLASTIC HEAD PAD BACKING 1
35 022-01PD2058-5 PLASTIC BACK PAD BACKING 1
PART LIST
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
PAGE 33
OWNER'S MANUAL
RS-1302 ASSEMBLY
