PARTS LIST
CUSTOMER CATALOG Page 14
31 19-WSB-1123 RUBBER WEIGHT STACK BUMPER 2
Key
No. Qty. Part Number Description
32 26-STD-SG117 GUIDE ROD : 44 1/2" 2
33 26-STD-PLAS142 PULL PIN HOLDER 1
34 14-OIL-34F 3/4" I.D. x 1" O.D. FLANGED OILITE 4
35 26-SDT-SU1011T 10 x 11 TAPERED PAD 1
36 26-STD-SU1020 10 x 20 PAD 1
37 26-STD-SU1017 10 x 17 PAD 1
38 18-PUL-412 4 1/2 PULLEY 3
39 10-SCA-SC2958 SHRUG CABLE 1
40 10-SCA-SC9234 SHOULDER CABLE 1
41 14-BRG-MR16N BEARING 4
42 16-CAP-112212 1 1/2 x 2 1/2 END CAP 4
43 26-STD-PLAS125 E-Z GLIDE SLEEVE 4
44 19-PLG-1 RUBBER BUMPER PAD 2
45
46
47
48
49 19-GRP-78COMFORT
26-STD-SM134
15-RNG-58
10-LRD-12
16-CAP-23 COMFORT GRIP
WEIGHT STACK PIN
SPLIT RING
COIL SPRING
END CAP 2 x 3 4
1
2
1
2
50 16-GRP-34 3/4 DIA. END CAP 1
