Legatia Pro User’s Manual ©Hybrid Audio Technologies Page 27 of 43
IN - Woofer negative input from amplifier
+WF Woofer positive output to Hybrid Audio Technologies midbass or midrange positive terminal
OUT - Woofer negative output to Hybrid Audio Technologies midbass or midrange negative terminal
+M/TW Midrange and tweeter positive input from amplifier
IN -
Midrange and tweeter negative input from amplifier
+M/H Midrange positive output to Hybrid Audio Technologies midrange positive terminal, 0 dB
setting
+M/L Midrange positive output to Hybrid Audio Technologies midrange positive terminal, -3 dB
setting
+T/H Tweeter positive output to Hybrid Audio Technologies tweeter positive terminal, +3 dB setting
+T/M Tweeter positive output to Hybrid Audio Technologies tweeter positive terminal, 0 dB setting
+T/L Tweeter positive output to Hybrid Audio Technologies tweeter positive terminal, -3 dB setting
TW - Tweeter negative output to Hybrid Audio Technologies tweeter negative terminal
NOTE: the L3x is a bi-wired crossover, meaning the crossover has two sets of inputs for use with two
two-channel amplifiers or a four-channel amplifier. If you wish to not use two two-channel amplifiers
or a four-channel amplifier, and use only one two-channel amplifier instead, simply “bridge” the
connections between + WF and + M/T and IN – and IN – with two short strands of insulated wire.
Once all speakers are installed, you will need to do a brief listening test with CD-quality music that
you are intimately familiar with to determine which midrange and/or tweeter attenuation you desire.
Be sure that all equalization, bass, and treble levels are defeated or set to “zero” on the source unit
before evaluating the intensity of the tweeters with respect to your midrange/midbass level and your
listening taste. Note also, after approximately 25 hours, the speakers will begin to “break in”, like any
mechanical component, and intensities may need to be re-adjusted again. In other words, the
midbass and midrange need to be broken in with typical play-time before final midrange and tweeter
attenuation is set. You may find that after break-in, the midrange and/or tweeter intensity will need to
be re-adjusted.
Mounting
Choose your L3x mounting location carefully. The L3x contains parts that are susceptible to damage
through repeated shock, moisture, and electromagnetic interference. For example, it is advisable to
install the passive crossovers inside the passenger compartment versus the door, since the door is
exposed to repeated opening and closing “shock” which may damage the delicate passive crossover
components, or cause soldered joints to break over time. Likewise, moisture may be present in a
door installation. Finally, if you are mounting the passive crossovers in the kick panels or dashboard,
be sure to keep the networks away from any noise-inducing device within the vehicle, such as factory
ECU’s, auto transmission control ECU’s, BCM’s, alternator field/stator wiring, and numerous other
devices. Readers note: be mindful of the location of throttle, brake, and clutch pedals when you are
selecting a mounting location and where to route the speaker wiring.
If the only option for crossover mounting is in the door, it would typically be prudent to install the
passive crossovers immediately adjacent to the midbass location to keep speaker wiring and
connections short and allow access to the OEM wiring, if it is used, without having to extend it and
creating an additional resistive splice in the wire. If you must install the L3x in the door, DO NOT
MOUNT THE CROSSOVER INSIDE THE DOOR CAVITY! Rather, install the networks on the same
mounting plane as the midbass, toward the passenger compartment, and behind the OEM door
