Kawai CA97 - Manual (Page 68)

68
Set
tings
User Tone Control
The User Tone Control option allows finer control over the instrument’s sound character, allowing the volume of
four frequency bands to be adjusted individually. It is also possible to adjust the frequency range of the mid-low
and mid-high frequency bands.
„User Tone Control setting
No. User Tone Control Description
1 Low Adjusts the volume of the low range frequency band (20~100 Hz).
2 Mid-low Frequency Adjusts the frequency of the mid-low band (355~3150 Hz).
Mid-low dB Adjusts the volume of the mid-low range frequency band.
3 Mid-high Frequency Adjusts the frequency of the mid-high band (355~3150 Hz).
Mid-high db Adjusts the volume of the mid-high range frequency band.
4 High Adjusts the volume of the high range frequency band (5000~20000 Hz).
1. Selecting the User Tone Control setting
After selecting the Tone Control setting (page 67):
Press the e or f buttons to select the User Tone Control type,
then press the FUNCTION button (EDIT).
The User Tone Control screen will be shown in the LCD display.
2. Selecting and adjusting the User Tone Control settings
Press the d or c buttons to select the User Tone Control
setting.
Press the e or f buttons to increase or decrease the value of
the selected User Tone Control setting.
* Each User Tone Control band can be adjusted within the range of
–6 dB~+6 dB.
* To reset the User Tone Control setting to the default type, press the
e and f buttons simultaneously.
* Any changes made to the User Tone Control setting will remain until
the power is turned off.
* Preferred User Tone Control settings can be stored to the Startup
Setting memory for convenient recall. Please refer to page 77 for
more information.
3. Exiting the User Tone Control setting
Press the FUNCTION button (BACK) to exit the User Tone
Control setting and return to the Tone Control setting.
Basic Settings
