CONTROL ELEMENTS:
1 ON / OFF
On/off switch complete unit.
2 AC CORD CONNECTION
Connect the main power cable here.
3 TRACK SELECT
Pressing 0-9 Buttons allows you to directly select tracks from a CD, USB stick or SD card.
4 PITCH "-"
The pitch is adjustable from 0% to -16% in 8 steps.
5 PITCH "+"
The pitch is adjustable from 0% to +16% in 8 steps.
6 CD SLOT
Insert your AUDIO CD here.
7 FOLDER SKIP
Press the left button once to go to the first file of the previous folder, or the right button to go to the first file
of the next folder.
8 << AND >>
<< Button: Use this button to restart the track or to select the previous track. Press the button more than
1sec and the double-quick backwards function will start.
>> Button: Use this button to select the next track. Press the button more than 1 sec and the double-quick
forward function will start.
9 STOP
Press to stop playing.
10 PLAY / PAUSE
Press to switch between play and pause.
11 EJECT
Ejects your CD
12 USB PORT
Insert a USB Memory Stick
13 SD CARD PORT
Insert SD Card with contacts facing right.
14 DISPLAY
Backlight LCD Display
