Troubl
eshooting
Information
HDMI
Control
Function
Pl
ayback
Connections
Getting Started
Specifications

ENGLISH
Setting items Setting contents
File filter
Selects the file format you
want· to· play· back· from·
among the files mixed on a
disc.· All :·Plays·back·MP3/WMA/AAC/LPCM/JPEG/DivX® files.
Audio : Plays back MP3/WMA/AAC/LPCM files.
Picture : Plays back JPEG files.
Video :·Plays·back·DivX® files.
Audio & Picture : Plays back MP3/WMA/AAC/LPCM/JPEG files.
This·operation·is·effective·only·when·playback·is·stopped.·
Setting items Setting contents
Secondary Video (PIP) Off : Does·not·display·Secondary·Video(Picture-In-picture).
1/Xz : Displays the first Secondary Video.
2/Xz :·Displays·the·second·Secondary·Video.
X/Xz :·Displays·the·X·th·Secondary·Video.
z
：·“X”· is· the· number· of· Secondary· Videos· recorded· and· differs·
depending·on·the·disc·(“Playing·Bonus·View”·vpage·35)
Audio/Video Sync
·Correct· displaced· video-
audio·playback·timing. HDMI / Component :·Audio·output·is·synchronized·to·the·video·output·
from·the·HDMI·terminal·or·component·terminals.
·
S-VIdeo /Video :·Audio·output·is·synchronized·to·the·video·output·from·
the·S-Video·or·Video·terminals.
Audio Delay Adjust
While·
viewing· video,·
manually· adjust· the· time· to·
delay·audio·output.
0 ~ 200msec :·Use·this·to·adjust·the·audio·output·delay·time·manually.
Vertical Stretch
Extends·
cinemascope·
size· video· in· the· vertical·
direction.·
Off : Displays the source video signal without modification. This should
normally·be·set·to·“Off”.
On :·Set·when·viewing·cinemascope·size·video·with·a·combination·of·
projector·and·anamorphic·lens.·Extends·the·image·in·the·vertical·direction·
so·that·the·top·and·bottom·black·portions·disappear.
NOTE
This·has·no·effect·with·the·video·and·S-Video·outputs.
Changing the Playback File Display Default settings are
underlined.
Making Other Settings
Default settings are underlined.
You can set the audio mode and change playback files.
You can set various modes during playback. The setting menu is displayed at the top of the screen.
Various Settings
Setting items Setting contents
BD Audio Mode
Switch· BD· audio· playback·
mode. HD Audio Output :·Can·view·by·outputting·high·quality·signals·such·as·
Dolby· TrueHD,· Dolby· Digital· Plus,· or· DTS-HD· as· its· high· sound· quality·
bitstream.·Cannot·listen·to·interactive·or·secondary·audio.
Mix Audio Output :· Outputs· a· mix· of· primary· audio/interactive· audio/
secondary·audio.
NOTE
When·“BD·Audio·Mode”·is·set·to·“Mix·Audio·Output”,·DTS-HD·192kHz·
audio·is·decoded·to·96kHz.
1
Press .
Displays·the·currently·settable·menu.·
The·display·content·changes·depending·on·the·media·being·played·back.· b
2
Select the setting item using , and then press or .
3
Use to select a setting and use to change the setting.
Vertical Stretch
All
Off
BD Audio Mode Mix Audio Output
File filter
Setting the Audio Mode
Default settings are underlined.
Setup
