CAB CONTROLS, ANALOG (STANDARD)
– 6 Spray Heads & Timer
– Water Level
– Drain & Dump Bar
– Water Cannon & Adjust.
Nozzle
– Work Lights
** 041903 DOES NOT INCLUDE ITEM 11 – SOLENOID DRIVER CARD
ITEM PART NO DESCRIPTION QTY
SPARE
PART
044014 CAB CONTROL, W/ DRIVER CARD
** 041903 CAB CONTROL, W/O DRIVER CARD
1 303041 JOYSTICK, UNIVERSAL 1 X
2 305019 SWITCH, GREEN LENS, SPST 11 X
3 305020 SWITCH, WHITE LENS, SPST 1 X
4 305022 SWITCH, MOMENTARY 1 X
5 305021 SWITCH, NO LIGHT, DPDT 8 X
6 303128 COVER, CARLING SWITCH 5
7 305029 KNOB, POTENTIOMETER 2 X
8 303821 WATER LEVEL INDICATOR 1
9 304751 TIMER 1 X
10 303824 CALIBRATION TOOL, W.L. 1
11 305078 DRIVER CARD, SOLENOID 1
9
11
10
8 7
1
2
3
4 5
6
